Clack Water Softener WS1 CI – 50 ltr 2 m3/hr

Introducing the Clack WS1 CI Water Softener –  Your Solution for Reliable Soft Water!

Are you looking for a water softening solution that perfectly balances efficiency and performance? Look no further than the Clack WS1 CI simplex water softener.

Superior Softening Performance: The Clack WS1 CI water softener employs a single high-quality vessel paired with top-grade softening resin. This winning combination ensures your water is softened to perfection.

Seamless Regeneration: Don’t worry about interrupted water supply during the regeneration process. The WS1 valve intelligently manages regeneration during low water usage periods, such as when residents are asleep. This ensures that you always have a consistent and reliable supply of soft water without disruptions.

Tailored Regeneration: With meter-controlled systems, you benefit from advanced technology that calculates the exact amount of soft water processed. This intelligent system then initiates the regeneration process based on pre-calibrated settings. We can also customise the regeneration timing to suit your specific needs, ensuring maximum convenience and efficiency.

Our Clack WS1 CI water softeners are meticulously crafted by our team of seasoned engineers. This dedication to quality ensures unrivalled reliability, making our softeners the perfect choice for both residential and commercial applications. With a typical resin life expectancy of 10 to 15 years, you can trust that your investment will stand the test of time.

---

Clack WS1 CI Key Information

Ref	Description	Tank Size	Resin Quantity	Flow Rate	* Capacity @ 300 ppm	** Salt Usage Per Regen
SS20-C1	20 Litre,WS1 Metered Softener	8” x 35”	20 Litres	0.8 m3/hr	3.33 m3	2.4 kg
SS30-C1	30 Litre,WS1 Metered Softener	10” x 35”	30 Litres	1.2 m3/hr	5.00 m3	3.6 kg
SS40-C1	40 Litre,WS1 Metered Softener	10” x 44”	40 Litres	1.6 m3/hr	6.66 m3	4.8 kg
SS50-C1	50 Litre,WS1 Metered Softener	10” x 54”	50 Litres	2.0 m3/hr	8.33 m3	6.0 kg
SS60-C1	60 Litre,WS1 Metered Softener	12” x 52”	60 Litres	2.4 m3/hr	10.00 m3	7.2 kg
SS75-C1	75 Litre,WS1 Metered Softener	13” x 54”	75 Litres	3.0 m3/hr	12.50 m3	9.0 kg
SS100-C1	100 Litre,WS1 Metered Softener	14” x 65”	100 Litres	4.0 m3/hr	16.66 m3	12.0 kg
SS150-C1	150 Litre,WS1 Metered Softener	16” x 65”	150 Litres	6.0 m3/hr	25.00 m3	18 kg
* Capacity based on 50g CaCO3 hardness removed per litre of resin.
** Salt usage based on 120g per litre of resin. This will increase if salt dosage is increased.



Clack WS1 CI Specification

Maximum Flow Rate	6.1 m3/hr
Drain Connections	3/4” Male BSP
Brine Line Connection	3/8” Push Fit
Riser Tube	1.05” ø
Body	Noryl
Electrical Rating	230-12V / 50Hz
Power Rating	0.5 Amps
Min Inlet Pressure	20psi -1.4 bar
Max Inlet Pressure	125psi - 8.6 bar
Average Pressure Loss Over System	1 bar
Min/Max Temperature	4℃ - 43℃



Clack WS1 CI Dimensions

Ref	Width	Depth	Height	Brine Tank Diameter ø	Brine Tank Height
SS20-C1	550 mm	450 mm	1100 mm	450 mm	940 mm
SS30-C1	600 mm	450 mm	1100 mm	450 mm	940 mm
SS40-C1	720 mm	450 mm	1330 mm	450 mm	940 mm
SS50-C1	720 mm	450 mm	1590 mm	450 mm	940 mm
SS60-C1	770 mm	450 mm	1540 mm	450 mm	940 mm
SS75-C1	1040 mm	700 mm	1590 mm	500 mm	1060 mm
SS100-C1	1090 mm	720 mm	1640 mm	500 mm	1060 mm
SS150-C1	1180 mm	770 mm	1640 mm	550 mm	1060 mm

All Industrial Water Equipment Softener kits come complete with everything required, you will just need to connect the inlet, outlet, drain and power.
