MIGHTY MINI
MIGHTY MINI TECHNICAL DATA
The ideal solution to unwanted oil in coolants and parts washers therefore extending the life of coolant and wash water! The Mighty Mini SST Oil Skimmer can remove 1 to 2 gallons of medium weight oil per hour (depending on belt selection ). Its stainless steel construction enables it to operate in harsh chemicals and heat while its integrated timer lets it run only when needed. The Mighty Mini SST Oil Skimmer is designed to minimise water content in the disposed oil; however the optional Oil Concentrator® will further reduce the water content in the oil to less than 2%. This provides tremendous cost saving if the oil is to be recycled or disposed.
It is compact making efficient use of available space… it fits underneath most CNC machines as well as inside parts washers. The small footprint even allows the Mighty Mini SST Oil Skimmer to fit through the bung hole of a 55 gallon drum! With belts specifically selected for your application available in lengths of 6, 12, 18 and 24″. This Oil Skimmer has endless application possibilities.
The Mighty Mini SST Oil Skimmer weighs only 8 pounds and the ease of installation make this skimmer the most versatile of our line. Use it here today and there tomorrow as it installs in just seconds.
Highlights
- A 1″ or 2″ continuous belt of corrosion resistant steel or elastomer
- Oil discharge via a 3-foot 3/4-inch diameter clear plastic hose with clamp
- Deep removable trough.
- 316 Stainless Steel Glass Beaded Finish
- 24 hour timer
- 8-foot grounded power cord w/plug
- Fractional fan-cooled gear motor
- Removes one or two gallons of medium weight oil per hour
| Model | Belt Width | Belt Length | RPM / Amps | Volts Hz | Phase |
| MM100ST-06 | 1" | 6" | 30 RPM - 1.5 -2.0A | 115 - 60Hz | 1 PH |
| MM100ST-12 | 1" | 12" | 30 RPM - 1.5 -2.0A | 115 - 60Hz | 1 PH |
| MM100ST-18 | 1" | 18" | 30 RPM - 1.5 -2.0A | 115 - 60Hz | 1 PH |
| MM100ST-24 | 1" | 24" | 30 RPM - 1.5 -2.0A | 115 - 60Hz | 1 PH |
| MM200ST-06 | 2" | 6" | 30 RPM - 1.5 -2.0A | 115 - 60Hz | 1 PH |
| MM200ST-12 | 2" | 12" | 30 RPM - 1.5 -2.0A | 115 - 60Hz | 1 PH |
| MM200ST-18 | 2" | 18" | 30 RPM - 1.5 -2.0A | 115 - 60Hz | 1 PH |
| MM200ST-24 | 2" | 24" | 30 RPM - 1.5 -2.0A | 115 - 60Hz | 1 PH |
| Oil Removal Rate |
| Model SMMS1-06: 1 gph (3.8 lph) with 1 in. (25.4 mm) wide belt, 6 in. (153 mm) length |
| Model SMMS1-12: 1 gph (3.8 lph) with 1 in. (25.4 mm) wide belt, 12 in. (305 mm) length |
| Model SMMS1-18: 1 gph (3.8 lph) with 1 in. (25.4 mm) wide belt, 18 in. (458 mm) length |
| Model SMMS1-24: 1 gph (3.8 lph) with 1 in. (25.4 mm) wide belt, 24 in. (610 mm) length |
| Model SMMS2-06-06: 2 gph (5.7 lph) with 2 in. (50.8 mm) wide belt, 6 in. (153 mm) length |
| Model SMMS2-12: 2 gph (5.7 lph) with 2 in. (50.8 mm) wide belt, 12 in. (305 mm) length |
| Model SMMS2-18: 2 gph (5.7 lph) with 2 in. (50.8 mm) wide belt, 18 in. (458 mm) length |
| Model SMMS2-24: 2 gph (5.7 lph) with 2 in. (50.8 mm) wide belt, 24 in. (610 mm) length |
| Motor |
| Fractional hp TEFC, 115 or 220 VAC, single phase, 60 Hz gear motor, including 8 foot cord with electrical plug Optional: 50 Hz motor is available |
| Belt Material |
| Specifically selected for your application (see Belt Selection page) |
| Wiper Material |
| Consult us for the material appropriate for your application. |
| Mounting Medthod |
| Flat base mount with oil discharge through a 3/4 in. ID hose |
TOTE-IT
With it’s patented design, the Tote-It oil skimmer is a dependable and effective means of removing oil from water. The single assembly unit can be used in any application where 115 VAC, 60 Hz power is available.
The Tote-It belt oil skimmer utilises a continuous belt and wiper to remove up to 12 gallons of oil per hour from the fluid surface. The belt operates on a motor and pulley system attached to a stabiliser bar that is immersed in the contaminated liquid. After traveling over the head pulley, the belt passes through tandem wiper blades where oil is scraped off both sides of the belt, and discharged through a 1-1/4 in. ID hose. The tail pulley has flanges which allow it to roll freely on the inside of the belt without becoming dislodged. It does not need to be fastened to the tank.
Oil skimming makes use of the differences in specific gravity and surface tension between oil and water. These physical characteristics allow the belt to attract oil and other hydrocarbon liquids from the surface of the fluid.
The Tote-It belt oil skimmer is especially well suited for parts washing and machining centre applications. By removing surface oil from a wash tank, the parts will not be recontaminated as they are withdrawn. Removing tramp oil from a coolant tank prevents excessive smoke and fumes due to oil burning during cutting operations. It also reduces bacteria growth in the tank, along with the resulting odour.
TOTE-IT TECHNICAL DATA
| Oil Removal Rate |
| 12gph (45.6 lph) with 4 in.( 10 cm) wide belt 6 gph (22.8 lph) with 2 in.( 5 cm) wide belt (Removal rate is based on 30 weight oil in water.) |
| Motor |
| Fractional hp gear motor, 115VAC, 60 Hz |
| Belt Width |
| Specify 4 in. (10 cm), or 2 in. (5 cm) |
| Belt Length |
| Standard lengths from 18" to 5' center to center (maximum length 10') |
| Belt Material |
| Specifically selected for your application (see Belt Selection page) |
| Wiper |
| Nitrile standard; CRV rubber, Ceramic/UHMW hybrid and Stainless steel optional. Specify wiper material based on temperature and fluid compatibility. |
| Mounting Method |
| lat base mount with oil discharge through a 1-1/4 in. I.D. hose |
| Weight |
| Complete assembly with stabilizer bar, tail pulley, and steel belt: 2 in. : average 34 lbs. (15.4 kg) 4 in. : average 36 lbs. (16.3 kg) ( Note: optional hose w/clamp and adapter weighs 2 lbs. (0.9 kg) |
Model 4
The Model 4 Oil Grabber is a dependable and effective means of removing oil from water and water-base solutions. Often, oil skimming by itself will reduce oil to an acceptable level of water purity. Depending on the characteristics of the liquid, it is possible for the Model 4 alone to reduce oil content to less than five parts per million in water. The unit can be used as a pretreatment before filtration, and in conjunction with coalescing systems as part of an industrial wastewater treatment plan.
Model 4 belt oil skimmer utilises a continuous belt and wiper to remove up to 20 gallons of oil per hour from the fluid surface. The belt, operating on a motor and pulley system, runs through contaminated liquid to pick up oil from the surface. After traveling over the head pulley, the belt passes through tandem wiper blades where oil is scraped off both sides of the belt and discharged. The tail pulley has flanges which allow it to roll freely on the inside of the belt without becoming dislodged. It requires no bearings and does not need to be fastened to the tank. If turbulent conditions exist, an optional tether and cage assembly prevents the tail pulley from being dislodged.
Oil skimming makes use of the differences in specific gravity and surface tension between oil and water. These physical characteristics allow the belt to attract oil and other hydrocarbon liquids from the surface of the fluid. The Model 4 can be used in tanks with depths as shallow as one foot, or as deep as 100 feet.
MODEL 4 TECHNICAL DATA
| Oil Removal Rate |
| 16 gph (60 lph) with standard tail pulley. 20 gph (75 lph) with high capacity tail pulley. (Removal rate is based on 30 weight oil in water.) |
| Tail Pulley |
| Specify standard or high capacity. (The high capacity option uses a patented pulley design that improves the adherence of oil to the inside |
| Motor |
| Fractional hp, TEFC, gear motor operating on either 115/230VAC, single phase, 60Hz or 230/460 VAC, Optional: 50Hz power source; explosion proof; drip proof; |
| Belt Width |
| 4 in. (10 cm). |
| Belt Length |
| User specified (up to 100', measured from the centre of head pulley to centre of tail pulley) |
| Belt Material |
| Specifically selected for your application |
| Wiper |
| Nitrile standard; CRV optional. Specify wiper material based on temperature and fluid compatibility. |
| Mounting Method |
| Standard: Bracket for customer-supplied steel channel, with oil discharge through the channel. Option: Flat surface mount with oil discharge through a 1-1/2 in (3.75 cm) NPT male pipe fitting. |
| Weight |
| Drive assembly and housing with motor, without belt or tail pulley: 71 lbs. (32 kg) max. Standard or high capacity tail pulley: 8 lbs. (3.6 kg) 4 ft. corrosion-resistant steel belt: 4 lbs.(1.8 kg) (belt weight varies according to actual length specified) |
Model 8
The Model 8 Oil Grabber is a dependable and effective means of removing oil from water and water-base solutions. Often, belt oil skimmers alone will reduce oil to an acceptable level of water purity. Depending on the characteristics of the liquid, it is possible for the Model 8 alone to reduce oil content to less than five parts per million in water. The unit can be used as a pretreatment before filtration, and in conjunction with coalescing systems.
The Model 8 belt oil skimmer utilises a continuous belt and wiper to remove up to 40 gallons of oil per hour from the fluid surface. The belt, operating on a motor and pulley system, runs through contaminated liquid to pick up oil from the surface. After traveling over the head pulley, the belt passes through tandem wiper blades where oil is scraped off both sides of the belt and discharged. The tail pulley has flanges which allow it to roll freely on the inside of the belt without becoming dislodged. It requires no bearings and does not need to be fastened to the tank. If turbulent conditions exist, an optional tether and cage assembly prevents the tail pulley from being dislodged.
Oil skimming makes use of the differences in specific gravity and surface tension between oil and water. These physical characteristics allow the belt skimmer to attract oil and other hydrocarbon liquids from the surface of the fluid. The Model 8 can be used in tanks with depths as shallow as one foot, or as deep as 100 feet.
MODEL 8 TECHNICAL DATA
| Oil Removal Rate |
| 32 gph (120 lph) with standard tail pulley.40 gph (150 lph) with high capacity tail pulley.(Removal rate is based on 30 weight oil in water. |
| Tail Pulley |
| Specify standard or high capacity.(The high capacity option uses a patented pulley designthat improves the adherence of oil to the insideof the belt, thus increasing the removal rate.) |
| Motor |
| Fractional hp, TEFC, gear motor operating on either115/230VAC, single phase, 60Hz or 230/460 VAC, three phase, 60Hz.Optional: 50Hz power source; explosion proof; drip proof; pneumatic; and wash down duty motors. |
| Belt Width |
| 8 in. (20 cm) |
| Belt Length |
| User specified See Belt Selection |
| Belt Material |
| Specifically selected for your application |
| Wiper |
| Nitrile standard; CRV optional. Specify wiper material based on temperature and fluid compatibility. |
| Mounting Method |
| Standard: Bracket for customer-supplied steel channel,with oil discharge through the channel.Option: Flat surface mount with oil discharge through a3 in (7.5 cm) NPT male pipe fitting. |
| Weight |
| Drive assembly and housing with motor, without belt ortail pulley: 82 lbs. (37 kg) max.Standard tail pulley: 10 lbs. (4.5 kg).Optional high capacity tail pulley: 8 lbs. (3.6 kg)4 ft. corrosion-resistant steel belt: 7 lbs.(3.2 kg) (belt weight varies according to actual length specified) |
SKIMMER BELTS
 | Standard Poly Belts Reinforced to resist stretching, able to withstand reasonably high temperatures (up to 170°F), and textured to retain a small amount of oil, thus drawing more oil to itself on subsequent passes. Used where rust inhibitors and temperature are a component of the wash water or where UV sensitivity is an issue. Picks up some emulsified oils. Used On: All belt skimmers |
 | Elastomer Belts Can handle abrasive and harsh environments. Used where rust inhibitors are a component of the wash water. Used On: All belt skimmers |
 | Corrosion Resistant Steel Belts One of our most popular oil belt skimmer materials. Works well in most industrial applications where rust inhibitors are not a component of the wash water. Used On: All belt skimmers except PetroXtractor |
 | XP Poly Belts Similar to the Standard Polymer but for higher temperature applications (up to 180°F continuous). Also used when a smoother surface is required. Used On:All belt skimmers |
 | LFO (Fuzzy Belt®) Poly Belts Exceptional performance on light, non-viscous hydrocarbons, such as gasoline, where rate of recovery is an important factor. Resists stretching. Used On:All belt skimmers except Might Mini |
 | Looped (Fuzzy Belt®) Poly Belts For high temperature and harsh applications that standard Fuzzy Belts cannot tolerate. Used On: All belt skimmers except Mighty Mini |
